Uso previsto:
15 inch high brightness color LCD/touch screen;Various operation modes of buttons, knobs and touch screens;Support multi-channel 8 waveform with screen display;It has the analysis of arrhythmia, which supports three modes of monitoring, monitoring and operation.Blood oxygen saturationdetection accuracy high, support weak pulse detection function;The non-invasive blood pressure measurement supports manual, automatic and continuous mode, which can meet the needs ofmonitoring in various situations and greatly reduce the work intensity of medical staffff.It has 400 sets of blood pressure lists,6,000sec waveform review, 60 alarm record reviews, 7 days trend chart storage function;Voice, text and visual alarm function, level 3 alarm, provide physiological alarm and technical alarm, the lower limit of physiologi-cal alarm can be set according to need;Support multiple interface display: standard interface, trend coexistence interface, oxyCRG interface, large font interface;Supports multiple languages: Chinese, English, Spanish, polish, Turkish, French, Portuguese, Russian;Built-in high capacity battery, long battery life, easy to transfer animals;Optional print output function, support alarm trigger print;Anti - defifibrillation, anti - frequency electric knife interference. Support for wired orwireless central monitoring systems;Optional extension function module (dual channel IBP, ETCO2), plug and play, softwareautomatic recognition, interface dynamic adjustment,The module can be hot-plug;It can be used in cats, dogs, pigs, horses and other small, medium and large animals.Animal special accessories for difffferent types of animals;Dimensioni: 15,1 pollici
Peso: 4.4kgElectrical Specification: 100-240v AC, 50/60Hz, Max Input Power: 70VABattery: 11.1V 2200mAh ricarica della batteria di litio configurazione standard: SpO2, PR, NIBP, ECG, RESP, configurazione temporanea: Nellcor SpO2, 2-IBP, ETCO2, Touch screen, pacchetto integrato di stampanti termali Include:1 x device1 x Li-Battery1 x linea1 x Earth wire1 x Earth wire1 x Blood oxygen probe (per SpO2, PR)1 x Blood pressure cuff (per ECG, RESP)1 x Temperature probe (per Temperature)
| ECG | |
| Input | 3/5 wire ECG cable |
| Lead section | I II III aVR, aVL, aVF, V |
| Gain selection | *0.25, *0.5, *1, *2, Auto |
| Sweep speed | 6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s |
| Heart rate range | 15-30bpm |
| Calibration | ±1mv |
| Accuracy | ±1bpm or ±1% (select the bigger data) |
| NIBP | |
| Test method | Oscillometer |
| Philosophy | Adult, Pediatric and Neonate |
| Measurement type | Systolic Diastolic Mean |
| Measurement parameter | Automatic, Continuous measurement |
| Measurement method Manual | mmHg or ±2% |
| SPO2 | |
| Display Type | Waveform, Data |
| Measurement range | 0-100% |
| Accuracy | ±2% (between 70%-100%) |
| Pulse rate range | 20-300bpm |
| Accuracy | ±1bpm or ±2% (select the bigger data) |
| Resolution | 1bpm |
| 2-Temperature (Rectal & Surface) | |
| Number of channels | 2 channels |
| Measurement range | 0-50ºC |
| Accuracy | ±0.1ºC |
| Display | T1, T2, |
| Unit | ºC/ºF selection |
| Refresh cycle | 1s-2s |
| Respiration (Impedance & Nasal Tube) | |
| Measurement type | 0-150rpm |
| Accuracy | ±1bm or ±5%, select the bigger data |
| Resolution | 1rpm |
| Packing Information | |
| Packing size | 37*37*28cm |
| N.W. | 6kg |
| G.W. | 7kg |
